EP2C612D8 Series
12 13
English
No. Description
34 CPU PECI Mode Jumper (PECI_SEL1)
35 Descriptor Security Override Jumper (J100)
36 PMBUS Mode Jumper (PMBUS_SEL_DAT1)
37 TPM Header (TPM1)
38 PMBUS Mode Jumper (PMBUS_SEL_ALT1)
39 BMC SMBus Header (BMC_SMB_3)
40 Rear Fan Connector (REAR_FAN1)
41 BMC SMBus Header (BMC_SMB_2)
42 BMC SMBus Header (BMC_SMB_1)
43 PMBUS Mode Jumper (PMBUS_SEL_CLK1)
44 Intelligent Platform Management Bus header (IPMB_1)
45 Non Maskable Interrupt Button (NMI_BTN1)
46 2 x 288-pin DDR4 DIMM Slots (DDR4_E, DDR4_F, Blue)
47 CPU 2 Fan Connector (CPU2_FAN)
*For DIMM installation and conguration instructions, please see p.23 (Installation of Memory Modules
(DIMM)) for more details.
