Daikin UATY09KTAL [10/87] Ed43 441 specifications
![Daikin UATY09KTAL [10/87] Ed43 441 specifications](/views2/1694785/page10/bga.png)
ED43-441 Specifications
Packaged Air Conditioners UATY-K Series 9
3.2 60Hz
Note: 1. The above data marked with *1 are rated in accordance with 27°CDB (80°FDB) 19.5°CWB (67°FWB)
indoor temp. and 35°CDB (95°FDB) outdoor temp. at HI fan speed, 380V.
Above cooling capacities do not include indoor fan motor heat. (Gross)
2. The above data marked with *2 are rated in accordance with 29°CDB (84°FDB) 19°CWB (66°FWB) indoor
temp. and 46°CDB (115°FDB) outdoor temp. at HI fan speed, 380V.
3. The above data marked with *3 are rated in accordance with 20°CDB (68°FDB) indoor temp, and 7°CDB /
6°CWB (45°FDB / 43°FWB) outdoor temp.
Above heating capacities include indoor fan motor heat. (Net)
4. Operative up to 52°C in cooling, down to -10°C in heating.
5. The figures of *2 are reference value.
Model UATY06KTAL, YAL UATY08KTAL, YAL UATY09KTAL, YAL UATY12KTAL, YAL
*1 Cooling Capacity USRT 5 6 7.5 10
kW 17.7 22.0 26.4 35.1
Btu/h 60,300 75,000 90,000 120,000
kcal/h 15,200 18,900 22,700 30,200
*2 Cooling Capacity kW (15.5) (19.8) (23.8) (31.6)
Btu/h (52,900) (67,600) (81,200) (107,800)
*3 Heating Capacity kW 18.1 23.0 26.9 36.1
Btu/h 62,000 78,600 91,700 123,000
kcal/h 15,600 19,800 23,100 31,000
Capacity Steps % 100-0 100-0 100-0 100-0
Connections Drain Piping FPS3/4B FPS3/4B FPS3/4B FPS3/4B
Ducting Return (H×W) mm 530×932 488×917 488×917 576×952
Supply (H×W) mm 270×739 297×878 297×878 297×878
Casing / Color Paintable Galvanized Steel Plate / Ivory White
Indoor Coil Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Rows×Stages×Fin Pitch 2×24×2.0 3×22×2.0 3×22×2.0 3×26×2.0
Face Area m² 0.491 0.443 0.443 0.543
Indoor Fan Type Sirocco Fan
Drive Belt Drive
Air Flow Rate m³/min 52 68 68 100
cfm 1,840 2,400 2,400 3,530
Ext. Static Pressure mmH
2
O 9 10 10 10
Motor Output kW 0.75 1.5 1.5 1.5
Compressor Type Hermetically Sealed Scroll Type
Model TAL JT190B JT190B JT265D-P1 JT335D-P1
YAL JT190B-YH JT190B-YH JT265D-P1YH JT335D-P1YH
Motor Output kW 4.5 4.5 7.5 9.0
Refrigerant Model R22
No. of Refrigerant Circuits 1 1 1 1
Charge kg 3.2 4.4 4.4 5.5
Refrigerant
Oil
Model SUNISO 4GSDID-K
Charge L 1.6 2.7 2.7 2.7
Outdoor Coil Type Cross Fin Coil (Waffle Louver Fins and Hi-XA Tubes)
Rows×Stages×Fin Pitch 2×50×2.0 2×40×2.0 2×40×2.0 2×50×2.0
Face Area m² 1.26 1.57 1.57 1.97
Refrigerant Control Capillary Tube
Outdoor Fan Type Propeller
Model P52H11S P52H11S P52H11S P52H11S
Air Flow Rate m³/min 95 160 160 190
cfm 3,353 5,648 5,648 6,707
Motor Output W 230 230+190 230+190 230+190
Safety Devices Thermal Protector for Compressor and Outdoor Fan Motor. High Pressure Switch.
Over Current Relay (Compressor and Indoor Fan Motor). Reverse Phase Protector. Fuse.
Dimensions H×W×D mm 1,490×690×1,750 1,270×1,600×1,280 1,270×1,600×1,280 1,490×1,600×1,280
Weight kg 230 304 328 344
Drawing No. TAL C : 4D014888 C : 4D014889
YAL C : 4D014891 C : 4D014892
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
