ED43-441 Sound Level
Packaged Air Conditioners UATY-K Series 45
10.Sound Level
10.1 Overall Sound Level
Note: Operation sound differs with operation and ambient conditions.
dB(A)
Model 50/60Hz Measuring Location in Anechoic Chamber
UATY06K 62
UATY08K 63
UATY09K
UATY10K 64
UATY12K
UATY15K 66
UATY18K
UATY21K 67
4D013870
