3. Web GUI Overview
3.1 Menu bar
The menu bar displays the following items.
• Power Status / UID Status
• Dashboard
• Sensor
• System Information
• Logs & Reports
• Settings
• Remote Control
• Image Redirection
• Power Control
• Miscellaneous
• Maintenance
• Sign out
Menu bar
5
