Si38-606 Capacity Range
General Information 5
3. Capacity Range
Outdoor Units
Indoor Units
Capacity Range 8HP 10HP
RXM 8M 10M
No of Indoor Units
to be Connected
13 16
Total Capacity
Index of Indoor
Units to be
Connected
100
~
260
125
~
325
Capacity Range
0.8
HP
1
HP
1.25
HP
1.6
HP
2
HP
2.5
HP
3.2
HP
4
HP
5
HP
8
HP
10
HP
Capacity Index 20 25 31.25 40 50 62.5 80 100 125 200 250
Ceiling Mounted
Cassette Type
(Double Flow)
FXC 20L 25L 32L 40L 50L 63L 80L — 125L — —
Ceiling Mounted
Cassette Type
(Multi Flow)
FXF — 25L 32L 40L 50L 63L 80L 100L 125L — —
Ceiling Mounted
Cassette Corner
Type
FXK — 25L 32L 40L — 63L — — — — —
Slim Ceiling Mounted
Duct Type
FXD-PVE
20P 25P 32P — — — — — — — —
FXD-PVET
20P 25P 32P — — — — — — — —
FXD-MVE
20M 25M 32M 40M 50M 63M — — — — —
FXD-MVET
20M 25M 32M 40M 50M 63M — — — — —
Ceiling Mounted Low
Silhouette Duct Type
FXYD 20KA 25KA 32KA 40KA 50KA 63KA — — — — —
Ceiling Mounted
Built-In Type
FXS 20L 25L 32L 40L 50L 63L 80L 100L 125L — —
Ceiling Mounted
Built-In (Rear
Suction) Type
FXYB 20K 25K 32K 40K 50K 63K 80K 100K 125K — —
Ceiling Mounted
Duct Type
FXM — — — 40L 50L 63L 80L 100L 125L 200L 250L
Ceiling Suspended
Type
FXH — — 32L — — 63L — 100L — — —
Wall Mounted Type
FXA 20L 25L 32L 40L 50L 63L — — — — —
Floor Standing Type
FXL 20L 25L 32L 40L 50L 63L — — — — —
Concealed
Floor Standing Type
FXN 20L 25L 32L 40L 50L 63L — — — — —
