Operation
GB
23
Automatic boost function
Parboiling takes place at power level 9 with the automatic boost function.
After a certain time the power level will switch down automatically to a lower
simmering setting (1 to 8).
When using the automatic boost function only the simmering setting with
which the food is to be cooked through needs to be selected since the
electronic unit switches down automatically.
The automatic boost function is suitable for dishes which are cold initially and
are then heated up at high power. These dishes do not need to be constantly
monitored when simmering (e.g. boiling meat for soups).
1. Press the
ON/OFF button
to switch on the hob.
2. Press the
plus button
once to immediately set the power level at 9.
The decimal point in the power setting display will light up for 10 seconds.
The button must be pressed again within 10 seconds otherwise the
decimal point will no longer light up.
3. Press the
minus button
several times to select a simmering setting
from 1-8. The automatic boost function will then have been activated.
4. The automatic boost function will operate as programmed. After a certain
time (see chart) the cooking process will be continued with the simmering
setting.
Cutting off the automatic boost function:
Set the power setting at “0”.
Note
If the required cooking level is selected after the decimal point has switched
off, the automatic boost function will not be activated.
Power
setting
Automatic boost function
Time (sec)
1
2
3
4
5
6
7
8
9
82
164
264
328
410
82
164
164
-
