Teka VT TC 2P.1 [9/16] Operation

Operation

Switching on the second element

(only for cooking zones with several circuits)

Two-circuit connection of the respective cooking zone can only be effected

after the corresponding cooking zone has been switched on.

1. Select the desired cooking level 1-9.

2. Switch on the second heating circuit with the

circuit activation key

The control lamp (dual circuit activation) will light up.

3. The outer heating circuit will be switched off when the

circuit activation

key

is pressed again.

The control lamp will go off.

Note

The activated heating circuits will automatically be deselected when the

cooking zone is switched off.

Lock / child safety device

The lock can be used to block operation and settings (e.g. power setting 4).

Only the ON/OFF button can be used to switch the hob off.

The lock can be activated both when the hob is switched on and when it is

switched off. An activated lock will remain activated even if the hob is

switched off! The lock hence also serves as a child safety device in order to

prevent the hob from being operated unintentionally or intentionally.

Activating the lock

1. Press the

lock button

until the buzzer sounds. The control lamp for

the lock will light up and go off after a few seconds. The lock has been

activated and the control sensors cannot be operated.

De-activating the lock

2. Press the

lock button

until the buzzer sounds. The control lamp for

the lock will go off and the lock will have been deactivated.

Deactivated lock: please note

If the ON/OFF button or any other button (apart from the lock button )

is pressed, a buzzer will sound and the control lamp for the lock will light up

briefly to remind the user that the lock has been activated.
