Griven MOLED GRAPHIC 20 [40/44] Attention

5.5 Setting DMX mode AL4376

The DMX mode can be set only by using the accessory AL2660 Weezerd 1. Refer to the manual of the accessory.

The order recipt is confirmed by the lighting of all the LEDs in sequence according to the selected DMX mode.

5.6 DMX Functions AL4376

Each unit uses from 6 to 120 DMX channels.

For each pixel see the following table:

DMX MODE DMX CHANNELS USED BY THE UNIT N° PIXELS

0 120 40

1 60 20

2 30 10

3 24 8

4 12 4

5 6 2

Attention!

In the absence of DMX signal, the LEDs will run a diaagnostic lighting test as soon as the fixture is powered and

then they will stay off.

DMX CHANNELS USED BY THE UNIT N° PIXELS

120 40

60 20

30 10

24 8

12 4

6 2

Function Value Description

Red 0-255 Proportional control 0-100% of the Red color

Green 0-255 Proportional control 0-100% of the Green color

Blue 0-255 Proportional control 0-100% of the Blue color
