PS 200 Ferroscan
1. General information
1.1 Safety notices and their meaning
-WARNING-
Draws attention to a potentially dangerous situation that
could lead to serious personal injury or fatality if the
instructions are not followed.
-CAUTION-
Draws attention to a potentially dangerous situation that
could lead to slight personal injury or damage to the
equipment or other property if the instructions are not
followed.
-NOTE-
Draws attention to an instruction or other useful infor-
mation.
1.2 Pictograms
Contents Page
1. General information 1
2. Description 2
3. Items supplied 3
4. Technical data 4
5. Safety rules 8
6. Before use 10
7. Operation 11
8. Care and maintenance 32
9. Troubleshooting 32
10. Disposal 33
11. Manufacturer’s warranty tools 33
12. EC declaration of conformity 34
Components
PS 200 S scanner
PSA 60 soft pouch
PS 200 M monitor
PSA 94 memory card
PSA 92 data cable
PSA 93 headset with microphone
PSA 61 soft pouch
PSA 62 shoulder belt
2 × PSA 80 battery
2 × PUA 80 battery charger
2 × supply cord
PSA 10/11 reference grid set
PUA 90 adhesive tape
PUA 70 marking pen set
PSA 90 PC software
PS 200 toolbox
The numbers refer to the corresponding illustrations.
The illustrations can be found on the fold-out cover pages.
Keep these pages open while studying the operating
instructions.
In these operating instructions, the designation « the
appliance » always refers to the PS 200 Ferroscan sys-
tem.
Location of identification data on the appliance
The type designation and serial number can be found on
the type identification plate on the appliance. Make a note
of this data in your operating instructions and always
refer to it when contacting your Hilti representative or
service center.
Type: PS 200 S scanner
Serial no.:
Type: PS 200 M monitor
Serial no.:
Warnings
General
warning
Read the
operating instructions
before use
Symbols
Return waste
material for
recycling
