7
en
4.3 Specifications
Maximum scanning speed
Memory type
Memory capacity
Screen type/size
Screen resolution
Dimensions
Weight (with PSA 80 battery)
Depth (mm)
20 40 50 60 80 100
#3 ±2 ±2 ±2 ±3 ±4 ±5
#4 ±2 ±2 ±2 ±3 ±4 ±5
#5 ±2 ±2 ±2 ±3 ±4 ±5
#6 ±2 ±2 ±2 ±3 ±4 ±5
#7 ±2 ±2 ±2 ±3 ±4 ±5
#8 ±2 ±2 ±2 ±3 ±4 ±5
#9 ±2 ±2 ±2 ±3 ±4 ±5
#10 ±2 ±2 ±2 ±3 ±4 ±5
#11 ±2 ±2 ±2 ±3 ±4 ±5
Depth (inch)
0.8 1.6 2.0 2.4 3.1 3.9
#3 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#4 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#5 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#6 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#7 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#8 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#9 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#10 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
#11 ±0.1 ±0.1 ±0.1 ±0.1 ±0.15 ±0.2
Depth (mm)
20 40 50 60 80 100
#10 ±2 ±2 ±2 ±3 ±4 ±5
#15 ±2 ±2 ±2 ±3 ±4 ±5
#20 ±2 ±2 ±2 ±3 ±4 ±5
#25 ±2 ±2 ±2 ±3 ±4 ±5
#30 ±2 ±2 ±2 ±3 ±4 ±5
#35 ±2 ±2 ±2 ±3 ±4 ±5
Depth (mm)
20 40 50 60 80 100
6 ±5
10 ±2 ±2 ±2 ±3 ±4 ±5
13 ±2 ±2 ±2 ±3 ±4 ±5
16 ±2 ±2 ±2 ±3 ±4 ±5
19 ±2 ±2 ±2 ±3 ±4 ±5
22 ±2 ±2 ±2 ±3 ±4 ±5
25 ±2 ±2 ±2 ±3 ±4 ±5
29 ±2 ±2 ±2 ±3 ±4 ±5
32 ±2 ±2 ±2 ±3 ±4 ±5
35 ±2 ±2 ±2 ±3 ±4 ±5
38 ±2 ±2 ±2 ±3 ±4 ±5
Depth (mm)
20 40 50 60 80 100
8 ±5
10 ±2 ±2 ±2 ±3 ±4 ±5
12 ±2 ±2 ±2 ±3 ±4 ±5
14 ±2 ±2 ±2 ±3 ±4 ±5
16 ±2 ±2 ±2 ±3 ±4 ±5
18 ±2 ±2 ±2 ±3 ±4 ±5
20 ±2 ±2 ±2 ±3 ±4 ±5
22 ±2 ±2 ±2 ±3 ±4 ±5
25 ±2 ±2 ±2 ±3 ±4 ±5
28 ±2 ±2 ±2 ±3 ±4 ±5
32 ±2 ±2 ±2 ±3 ±4 ±5
36 ±2 ±2 ±2 ±3 ±4 ±5
Value indicates typical accuracy of depth measurement
(deviation from actual) in mm or inches as applicable.
d. Quickscan detection
Depth measurement is typically accurate to within ±10 %
of the effective depth.
4.2.2 Accuracy of bar diameter measurement
±1 standard diameter when rebar spacing: depth of cover
2 :1. Bar diameter measurement is possible only at
depths of up to 60 mm.
4.2.3 Accuracy of rebar location
Relative bar center measurement accuracy (all modes),
typical: T ypically ±3 mm or typically ±0.1 inch relative to
the measured position, when the bar spacing: depth of
cover 1.5 :1.
Bar diameter (ASTM)Bar diameter (ASTM)Bar diameter
(CAN)
Bar diameter (JIS)
Bar diameter (GB 50010-2002)
PS 200 M monitor
--
Removable SD card, max. memory
card size: 1 GB
At least 150 Imagescans or 75 Quick-
scans (total 2250 m), plus up to
15 minutes of speech with 32 MB
card.
LCD/115 × 86 mm
320 × 240 pixels/16 gray scales
264 × 152 × 57 mm
1.40 kg
PS 200 S scanner
0.5 m/s
Built-in data flash memory
9 Imagescans plus up to 30 m
of recorded Quickscan
(max. 10 scans)
LCD/50 × 37 mm
128 × 64 pixels
260 × 132 × 132 mm
1.40 kg
Printed: 07.07.2013 | Doc-Nr: PUB / 5070390 / 000 / 00
