Zkteco FR1500 [2/8] Installation
![Zkteco FR1500 [2/8] Installation](/views2/1704665/page2/bg2.png)
Installation
1
Dimensions(mm)
Remove both the screws
STEP 1
Procedure to be followed before installation
Note: Not all the devices have the fingerprint cover. The real
product prevails.
BLACK
GND
12V
GND
485+
485-
PURPLE
YELLOW
BLACK
RED
77.3
121.3
7.1
38.0
83.3
72.0
61.0
