4
Mounting the device on wall
j Paste the mounting template sticker onto the wall, and drill holes according
to the mounting paper.
1.2m
k Fix the back plate onto the wall using wall mounting screws.
l Insert the device into back plate.
m Use security screw to fasten the device to back plate.
1
3
2
4
Installation & Printer Connection
RS232 cabel
Serial Printer
Printer Connection
