Zkteco IN05 [8/18] Lock relay connection
![Zkteco IN05 [8/18] Lock relay connection](/views2/1704789/page8/bg8.png)
7
Lock Relay Connection
GND
NC1
+12V DC
COM1
FR107 Diode
Normally Closed Lock
Device sharing power with the lock
-
+
!
Maximum12V2Ainput.
NC1
NO2
COM2
NC2
!
Do not reverse the polarity.
Do not use
