Ethernet & USB & Power Connection
LAN Connection
ZKTime Web
8
7
6
5
4
3
2
1
12V DC Adaptor
Power Connection
Recommended power supply
1) 12V ± 10%, at least 1500mA.
2) To share the power with other devices, use a power supply with higher current ratings.
3) Battery is an optional function. You may not use the UPS.
USB Connection
ZKTime Web
