MEAN WELL XLG-150-M-AB Datasheet онлайн
150W Constant Power Mode DriverLED
XLG-150 series
File Name:XLG-150-SPEC 2019-07-05
■ Description
■ Features ■ Applications
■ Model Encoding
XLG - 150
Rated wattage
Series name
AB
Type
A
L
Rated output voltage(12/24V or L/M/H types)
Function options
-
3 in 1 dimming function (0~10Vdc, 10V signal and resistance)PWM
In Stock
Function
Note
In Stock
Io adjustable via built-in potentiometer
Io adjustable via built-in potentiometer +
｛
I: for India version(by request with Input over voltage protection)
:For standard version
I
Note: 12V and 24V models without the typeAB
-
Blank
By request
Io and Vo fixed.(For harsh environment)
(Except for L type)
M M
110
SELV
Type HL
05
Note.12
Skyscraper lighting•
Street lighting•
Floodlight Lighting•
Stage lighting•
•
Fishing lighting
•Horticulture lighting
Bay lighting
•
DMX power supply•
Type HL for use in class I, Division 2•
•
Wide input range 100~305V AC( Class I)
•Full power output at 70~100% Constant power mode operation
•Metal case with IP67, suitable for outdoor application
•Surge protection with 6KV/4KV (10KV/6KV optional)
•3 in 1 dimming function (Dim to off and Isolation design)
•India (EESL) version with Input Over Voltage Protection can
survive input voltage stress of 440Vac for 48 hours
•Protection functions: OVP/SCP/OCP/OTP
•Life time >50,000 hrs. and 5 years warranty
E320521
(for 12,24 only)
(Except for L type)
XLG LED AC DC XLG-150 series is a 150W / driver featuring the constant power mode. -150 operates
from 100~305 and offers models with different rated current ranging between 700mA and 12500mA.VAC
Thanks to the high efficiency up to 93%, with the fanless design, the entire series is able to operate for
-40 ~+90 case temperature under free air convection. The design of metal housing and 67 ingressIP
℃℃
protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative
environment-adaptive capability allows this series to reliably light on the s for all kinds of applicationLED
environments in almost any spots that may install luminaires in the world. 150 series complyLED XLG-
with the latest version of 61347 7000 1 2015 and 8750 international safety regulations/.- .IEC GB UL
The output and dimming circuit are also completely in accordance with the new regulations with
isolation to ensure the safety of both user and luminaire system during installation.
(For 24V only)
LVLE
IS 15885(Part 2/Sec13)
R-41027766
THOMAS SAMUEL
THOMAS SAMUEL
(for XLG-150I type only )
