200W Constant Power Mode LED Driver

XLG-200 series

File Name:XLG-200-SPEC 2019-07-04

■ Description

■ Features

■ Applications

■ ModelEncoding

XLG - 200

Ratedwattage

Seriesname

Type

Ratedoutputvoltage(12/24V,orL/Htypes)

Functionoptions

3in1dimmingfunction(0~10Vdc,10VPWMsignalandresistance)

InStock

Function

Note

InStock

Ioadjustableviabuilt-inpotentiometer

Ioadjustableviabuilt-inpotentiometer+

｛

:Forstandardversion

(ExceptforLtype)

M M110

SELV

TypeHL

Note.12

Blank

Byrequest

IoandVofixed.(Forharshenvironment)

• Skyscraperlighting

• Streetlighting

• FloodlightLighting

• Stagelighting

• Fishinglighting

• Horticulturelighting

• Baylighting

• DMXpowersupply

• TypeHLforuseinclassI,Division2

• Wideinputrange100~305VAC(ClassI)

Fullpoweroutputat70~100%Constantpowermodeoperation•

• MetalcasewithIP67,suitableforoutdoorapplication

Surgeprotectionwith6KV/4KV(10KV/6KVoptional)•

• 3in1dimmingfunction(DimtooffandIsolationdesign)

• India(EESL)versionwithInputOverVoltageProtectioncan

surviveinputvoltagestressof440Vacfor48hours

• Protectionfunctions:OVP/SCP/OCP/OTP

• Lifetime>50,000hrs.and5yearswarranty

Note:12Vand24VmodelswithoutABtype

(ExceptforLtype)

XLG-200 series is a 200W LED AC/DC driver featuring the constant power mode. XLG-200 operates

from 100~305VAC and offers models with different rated current ranging between 700mA and 16A.

Thankstothehighefficiencyupto94%,withthefanlessdesign,theentireseriesisabletooperatefor

-40 ~+90 casetemperatureunderfreeairconvection.ThedesignofmetalhousingandIP67ingress℃ ℃

protection level allows this series to fit both indoor and outdoor applications. Moreover the innovative

environment-adaptivecapabilityallowsthisseriestoreliablylightontheLEDsforallkindsofapplication

environmentsinalmostanyspotsthatmayinstallLEDluminairesintheworld.XLG- 200 series comply

with the latest version of IEC61347/GB7000.1-2015 and UL8750 international safety regulations.

The output and dimming circuit are also completely in accordance with the new regulations with

isolation to ensure the safety of both userand luminaire system during installation.

I:forIndiaversion(byrequestwithInputovervoltageprotection)
