MEAN WELL XLG-200-L-A [2/9] Xlg 200

SPECIFICATION

MODEL

OUTPUT

VOLTAGE RANGE Note.5

FREQUENCY RANGE

POWER FACTOR

EFFICIENCY (Typ.)

AC CURRENT

INPUT

VIBRATION

MTBF

DIMENSION

OTHERS

NOTE

PACKING

OVER TEMPERATURE

OVER VOLTAGE

500ms, 100ms/230VAC, 1200ms, 100ms/115VAC

10ms/ 230VAC 10ms/ 115VAC

47 ~ 63Hz

2.2A / 115VAC 1.1A / 230VAC 0.9A/277VAC

SAFETY &

EMC

PROTECTION

Hiccup mode, recovers automatically after fault condition is removed

Shut down output voltage, re-power on to recover

SHORT CIRCUIT

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

WITHSTAND VOLTAGE

ISOLATION RESISTANCE

TOTAL HARMONIC DISTORTION

HOLD UP TIME (Typ.)

RIPPLE & NOISE (max.) Note.3

VOLTAGE TOLERANCE Note.4

CONSTANT CURRENT REGION Note.2

OVER CURRENT

COLD START 65A(twidth=550 s measured at 50% Ipeak) at 230VACμ ; Per NEMA 410

MAX. No. of PSUs on 16A

CIRCUIT BREAKER

3 units (circuit breaker of type B) / 6 units (circuit breaker of type C) at 230VAC

MAX. CASE TEMP.

4.Tolerance:includessetuptolerance,lineregulationandloadregulation.

5.De-ratingmaybeneededunderlowinputvoltages.Pleasereferto“STATICCHARACTERISTIC”sectionsfordetails.

6.Lengthofsetuptimeismeasuredatfirstcoldstart.TurningON/OFFthedrivermayleadtoincreaseofthesetuptime.

7.InputovervoltageonlyforXLG-200Iseries,andIserieswithoutUL/CSAcertificate.

8.Thedriverisconsideredasacomponentthatwillbeoperatedincombinationwithfinalequipment.SinceEMCperformancewillbeaffectedbythe

completeinstallation,thefinalequipmentmanufacturersmustre-qualifyEMCDirectiveonthecompleteinstallationagain.

9.Thisseriesmeetsthetypicallifeexpectancyof>50,000hoursofoperationwhenTcase,particularlytcpoint(orTMP,perDLC),isabout70 orless.℃

10.PleaserefertothewarrantystatementonMEANWELL'swebsiteathttp://www.meanwell.com

11.Theambienttemperaturederatingof3.5 /1000mwithfanlessmodelsandof5 /1000mwithfanmodelsforoperatingaltitudehigherthan2000m(6500ft).℃ ℃

12.ProductssourcedfromtheAmericasregionsmaynothavetheCCC/PSE/BIS/KClogo.PleasecontactyourMEANWELLsalesformoreinformation.

PF≧0.97/115VAC, PF≧0.95/230VAC, PF≧0.92/277VAC@full load

Tcase=-40 ~ +90℃ (Please refer to “ OUTPUT LOAD vs TEMPERATURE” section)

12V

16A

150mVp-p

8.4~ 12V

192W

0.85Kg;16pcs /14.2Kg /0.72CUFT

SAFETY STANDARDS Note.7

UL8750(type”HL”), CSA C22.2 No. 250.13-12; ENEC EN61347-1, EN61347-2-13 independent, EN62384;

GB19510.1,GB19510.14; EAC TP TC 004;IP67 approved

NO LOAD

POWER CONSUMPTION

Parameter

Conducted

Radiated

Harmonic Current

Voltage Flicker

EN61547

Parameter

ESD

I/P-O/P:3.75KVAC I/P-FG:2KVAC O/P-FG:1.5KVAC
