200W Constant Power Mode LED Driver
XLG-200 series
BLOCK DIAGRAM
PFC fosc : 50~120KHz
PWM fosc : 60~130KHz
DETECTION
PWM
CIRCUIT
O.L.P.
EMI FILTER
RECTIFIERS
POWER
SWITCHING
FILTER
&
RECTIFIERS
+V
-V
I/P
FG
CONTROL
O.V.P.
&
O.C.P.
PFC
CIRCUIT
PFC
CONTROL
O.T.P.
DIM+
DIM-
(AB Type)
DRIVING METHODS OF LED MODULE
※ I-V Operating Area
Recommend Performance Region
※ This series is able to work in either Constant Current mode (a
direct drive way) or Constant Voltage mode (usually through
additional DC/DC driver) to drive the LEDs.
Typical output current normalized by rated current (%)
100
60
(min.)
Vo(%)
50
100
Io(%)
(B)
Constant
Current area
(C)
Hiccup
Protection
(A)
Constant
Voltage area
In the constant current
depends on the configuration
Should there be any
at the output of the driver
region, the highest voltage
of the end systems.
compatibility issues, please
please contact MEAN WELL.
120V
140V
160V
180V
200V
220V
240V
260V
280V
300V
0mA 250mA 500mA 750mA 1000mA 1250mA
1050mA,190V
700mA,285V
1050mA,142V
700mA,142V
350mA,285V
20V
25V
30V
35V
40V
45V
50V
55V
60V
0mA 800mA 1600mA 2400mA 3200mA 4000mA 4800mA 5600mA
3500mA,56V
5550mA, 36V
5550mA, 27V
3700mA,27V
1750mA,56V
Recommend Performance Region
