MEAN WELL XLG-150-M-AB [8/9] Xlg 15
![MEAN WELL XLG-150-M-AB [8/9] Xlg 15](/views2/1705876/page8/bg8.png)
150W Constant Power Mode LED Driver
XLG-150 series
File Name:XLG-150-SPEC 2019-07-05
MECHANICAL SPECIFICATION
Case No.: 243A Unit:mm
※ Blank-Type
169
180
156
45.8
63
300±20
300±20
35
35.5
4- 4.5ψ
tc
SJOW 17AWGx3C
&H05RN-F 3x1.0mm
2
AC/L(Brown)
AC/N(Blue)
FG(Green/Yellow)
Vo-(Black)
Vo+(Red)
SJOW 17AWGx2C&05RN-F 2x1.0mm (for H,L,M)
2
SJOW 14AWGx2C(for 12,24V)
※ A-Type
169
180
156
45.8
63
300±20300±20
35
35.5
4- 4.5ψ
tc
SJOW 17AWGx3C
&H05RN-F 3x1.0mm
2
AC/L(Brown)
AC/N(Blue)
FG(Green/Yellow)
SJOW 17AWGx2C&05RN-F 2x1.0mm (for H,L,M)
2
Vo-(Black)
38.3
14
Vo+(Red)
SJOW 14AWGx2C(for 12,24V)
70
22
tc
70
22
tc
