150W Constant Power Mode LED Driver
XLG-150 series
File Name:XLG-150-SPEC 2019-07-05
※ AB-Type
AC/L(Brown)
AC/N(Blue)
FG(Green/Yellow)
INSTALLATION MANUAL
169
180
156
45.8
63
350 20±
300±20
35
35.5
4- 4.5ψ
tc
SJOW 17AWGx3C
&H05RN-F 3x1.0mm
2
70
22
tc
DIM-(White)
DIM+( )Blue
Vo+(Red)
Vo-(Black)
SJOW 17AWGx2C
&05RN-F 2x1.0mm
2
UL2517 20AWGx2C
300±20
