Fubag AGS22/05 [4/14] S technical pecifications

3s. Technical pecifications

www.fubag.ru

Omperator's anual

- 3 -

The manufacturer reserves himself the right to make the manual's content or function

change without any preliminary notification of the users.

tools

4. Installation and functioning

Connections

Control

- This device has the protective coating Before using clean it with the appropriate solution.

- Aerograph is intended for the operation with dry and clean air. As the compressed air can contain

moister and foreign substances causing corrosion and early wear out of the pneumatic tool it is

recommended to use the airline filter moister oil separator to be installed very close to the

aerograph.

- Pressure in the air duct is to be 2,5-3,0 bar Greater or smaller pressure may result in damages of

the aerograph and poor painting quality.

- Check and, if necessary, replace the damaged and worn-out parts of the tool.

- Make sure, that the push button and the nozzle is the operative condition

- Connect air hose to the air duct The recommended hose size is 8 mm

- Make sure that the connections with the air duct, tank and cover are tight. Leakage of paint and

compressed air is not accepted.

- Mix spraying material as provided by the manufacturer s instruction manual.

- It is possible to use all serial production paints for spraying or the lacquers having consistency as

an emulsion. If necessary water is to be diluted

1. Single control aerographs

Push trigger button to supply air / paint.

,-,

(/ ),

.–.

MODEL 110101 110107 110108

Action type

single independent dual

Diameter of the standard nozzle, mm 0,5 0,2, 0,3

Inlet diameter, inch 1/4 1/8

Air consumption at the operating pressure, l/min 11,0 9,0

Operating pressure, bar 2,0 1,0

Paint consumption, ml/min 2 1,5

Tank capacity, ml 22 7

Overall dimensions, mm 141х84х37 174х85х15

Weight, kg 0,184 0,3
