•VRV
®
Systems • Outdoor Unit
3
• Outdoor Unit • VRV
®
III-S heat pump • RXYSQ-P8V1
2 Specifications
Standard Accessories : Installation manual; Quantity : 1;
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Connection pipes; Quantity : 3;
2-1 Technical Specifications RXYSQ4P8V1B RXYSQ5P8V1B RXYSQ6P8V1B
Capacity range HP 4 5 6
Cooling capacity Nom. kW 11.2 (1) 14.0 (1) 15.5 (1)
Heating capacity Nom. kW 12.5 (2) 16.0 (2) 18.0 (2)
Capacity control Method Inverter controlled
Steps % 24 to 100
Power input - 50Hz Cooling Nom. kW 2.81 3.51 4.53
Heating Nom. kW 2.74 3.86 4.57
EER 3.99 3.42
COP 4.56 4.15 3.94
Maximum number of connectable indoor units 8 (12) \<br /\> 6 (13) 10 (12) \<br /\> 8 (13) 13 (12) \<br /\> 9 (13)
Indoor index
connection
Min. 50 62.5 70
Nom. -
Max. 130 162.5 182
Casing Colour Daikin White
Material Painted galvanized steel plate
Sound power level Cooling Nom. dBA 66 67 69
Sound pressure level Cooling Nom. dBA 50 51 53
Heating Nom. dBA 52 53 55
Operation range Cooling
Standard
Min. ºCDB -5
Max. ºCDB 46
Heating Min. ºCWB -20
Max. ºCWB 15.5
Refrigerant Type R-410A
Control Expansion valve
Circuits Quantity 1
Refrigerant oil Type Daphne FVC68D
Piping connections Liquid Type Flare connection
OD mm 9.52
Gas Type Flare connection (VRV®) \<br /\>
Braze connection (RA)
Flare connection (VRV®) \<br /\>
Braze connection (RA)
Braze connection
OD mm 15.9 (12) \<br /\> 19.1 (13) 15.9 (12) \<br /\> 19.1 (13) 19.1
Drain Quantity 3
OD mm 26x3
Heat insulation Both liquid and gas pipes
Total piping length System Actual m 300 (12) \<br /\> 115 (13) 300 (12) \<br /\> 135 (13) 300 (12) \<br /\> 145 (13)
Level difference OU - IU
Outdoor unit
in highest
position
m 50 (12) \<br /\> 30 (13) 50 (12) \<br /\> 30 (13) 50 (12) \<br /\> 30 (13)
Indoor unit in
highest
position
m 40 (12) \<br /\> 30 (13) 40 (12) \<br /\> 30 (13) 40 (12) \<br /\> 30 (13)
IU - IU Max. m 15
Defrost method Reversed cycle
Defrost control Sensor for outdoor heat exchanger temperature
