Daikin RXYSQ4P8V1B [6/32] Specifications
![Daikin RXYSQ4P8V1B [6/32] Specifications](/views2/1706880/page6/bg6.png)
• Outdoor Unit • VRV
®
III-S heat pump • RXYSQ-P8V1
•VRV
®
Systems • Outdoor Unit
4
2 Specifications
Notes
(1)Cooling: indoor temp. 27ºCDB, 19ºCWB; outdoor temp. 35ºCDB; equivalent piping length: 5m; level difference: 0m
(2)Heating: indoor temp. 20ºCDB; outdoor temp. 7ºCDB, 6ºCWB; equivalent refrigerant piping: 5m; level difference: 0m
(3)Sound power level is an absolute value that a sound source generates.
(4)Sound pressure level is a relative value, depending on the distance and acoustic environment. For more details, please refer to the sound level drawings.
(5)Sound values are measured in a semi-anechoic room.
(6)RLA is based on following conditions: indoor temp. 27ºCDB, 19ºCWB; outdoor temp. 35ºCDB
(7)Voltage range: units are suitable for use on electrical systems where voltage supplied to unit terminal is not below or above listed range limits.
(8)Maximum allowable voltage range variation between phases is 2%.
(9)Select wire size based on the value of MCA
(10)Use a circuit breaker instead of a fuse. MFA is used to select the circuit breaker and the ground fault circuit interrupter (earth leakage circuit breaker).
(11)MSC means the maximum current during start up of the compressor
(12)In case VRV® indoor units are connected
(13)In case RA indoors are connected
(14)Minimum Ssc (=Short-circuit power) value: Equipment complying with EN/IEC 61000-3-12: European/International Technical Standard setting the limits for harmonic currents
produced by equipment connected to public low-voltage systems with input current \>16A and ≤ 75A per phase
2-2 Electrical Specifications RXYSQ4P8V1B RXYSQ5P8V1B RXYSQ6P8V1B
Power supply Name V1
Phase 1N~
Frequency Hz 50
Voltage V 220-240
Voltage range Min. % -10
Max. % 10
Current Nominal
running
current (RLA)
- 50Hz
Cooling A 15.9 20.2 22.2
Current - 50Hz Maximum running current A 27.0
Starting current (MSC) A 15.9 20.2 22.2
Zmax List No requirements
Minimum circuit amps (MCA) A 27.0
Maximum fuse amps (MFA) A 32.0
Full load
amps (FLA)
Fan motor A 0.3
Fan motor 2 A 0.3
Wiring
connections -
50Hz
For power
supply
Quantity 3
Remark Earth wire included
For
connection
with indoor
Quantity 2
Remark F1,F2
Power supply intake Both indoor and outdoor unit
Field earth leakage breaker mA 300
