![Daikin RXYQ14MY1B [10/242] Outdoor units](/img/pdf.png)
Daikin RXYQ14MY1B [10/242] Outdoor units
![Daikin RXYQ48MY1B [10/242] Outdoor units](/views2/1707434/page10/bga.png)
Product Outline Si39-303
4 General Information
1.2.2 Outdoor Units
RXYQ5M RXYQ8M,10M RXYQ12M,14M,16M RXYQ18M, 20M
5HP 8,10HP 12,14,16HP 18, 20HP
RXYQ22M, 24M, 26M RXYQ28M, 30M, 32M
22, 24, 26HP 28, 30, 32HP
RXYQ34M, 36M RXYQ38M, 40M, 42M
34, 36HP 38, 40, 42HP
RXYQ44M, 46M, 48M
44, 46, 48HP
