Product Outline Si39-303
2 General Information
1. Product Outline
1.1 Model Names of Indoor/Outdoor Units
Indoor Units
Outdoor Units (Inverter Series)
Type Model Name Power Supply
Ceiling mounted
cassette type
(Double flow)
FXCQ 20M 25M 32M 40M 50M 63M 80M — 125M — —
VE
Ceiling mounted
cassette type
(Multi flow)
600×600
FXZQ 20M 25M 32M 40M 50M — — — — — —
Ceiling mounted
cassette type
(Multi flow)
FXFQ — 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling mounted
cassette corner
FXKQ — 25M 32M 40M — 63M — — — — —
Ceiling mounted
built-in type
FXSQ 20M 25M 32M 40M 50M 63M 80M 100M 125M — —
Ceiling mounted
duct type
FXMQ — — — 40M 50M 63M 80M 100M 125M 200M 250M
Ceiling
suspended type
FXHQ — — 32M — — 63M — 100M — — —
Wall mounted
type
FXAQ 20M 25M 32M 40M 50M 63M — — — — —
Floor standing
type
FXLQ 20M 25M 32M 40M 50M 63M — — — — —
Concealed Floor
standing type
FXNQ 20M 25M 32M 40M 50M 63M — — — — —
Series Model Name
Power
Supply
Inverter Heat Pump RXYQ 5M 8M 10M 12M 14M 16M 18M 20M 22M 24M 26M Y1B
Series Model Name
Power
Supply
Inverter Heat Pump RXYQ 28M 30M 32M 34M 36M 38M 40M 42M 44M 46M 48M Y1B
VE: 1
φ
, 220~240V, 50Hz, 1
φ,
220V, 60Hz
Y1B: 3
φ
, 380~415V, 50Hz
