4 | Chapter 1: Introducon
1�3 Specifications
Specicaons
CPU Support
Socket 1151 for Intel® Core i7 / i5 / i3 / Penum / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Wa
* Please refer to www.biostar.com.tw for CPU support list.
Chipset
INTEL® Z270 (Z270GTN)
INTEL® B250 (B250GTN)
Memory
Z270GTN : Supports Dual Channel DDR4 1866/2133/2400/3200(OC)
B250GTN : Supports Dual Channel DDR4 1866/2133/2400
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* DDR4-2400 for 7th Generaon Intel® Core™ Processor Family.
* Please refer to www.biostar.com.tw for Memory support list.
Storage
Z270GTN:
INTEL® Z270
4x SATA III (6Gb/s) : Supports AHCI, RAID 0, 1, 5, 10 & Intel® Rapid Storage Technology
1x M.2 - Key M (32Gb/s) : Supports PCI-E / SATA SSD & Intel® Optane Technology
1x U.2 (32Gb/s) : Supports Intel® Optane Technology
B250GTN:
INTEL® B250
4x SATA III (6Gb/s) : Supports AHCI
1x M.2 (32Gb/s) : Key M - Supports PCI-E & SATA SSD
1x U.2 (32Gb/s) : Supports Intel® Optane Technology
LAN
Intel i219V
10/ 100/ 1000 Mb/s auto negoaon, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Denion Audio, Hi-Fi(Front)
USB
6x USB 3.0 port (4 on rear I/Os and 2 via internal headers)
4x USB 2.0 port (2 on rear I/Os and 2 via internal headers)
Expansion Slots 1x PCIe 3.0 x16 Slot
Rear I/Os
1x PS/2 Mouse / Keyboard
1x DVI-D Port
1x HDMI Port
4x USB 3.0 Port
2x USB 2.0 Port
1x LAN port
5x Audio Jack
1x S/PDIF out
Internal I/Os
Z270GTN:
4x SATA III Connector (6Gb/s)
1x U.2 Connector (32Gb/s)
1x M.2 - Key E Slot : Supports 2230 Wi-Fi
1x USB 2.0 Header (each header supports 2 USB
2.0 ports)
1x USB 3.0 Header (each header supports 2 USB
3.0 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
2x 5050 LED Header
B250GTN:
4x SATA III Connector (6Gb/s)
1x U.2 Connector (32Gb/s)
1x USB 2.0 Header (each header supports 2 USB
2.0 ports)
1x USB 3.0 Header (each header supports 2 USB
3.0 ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
2x 5050 LED Header
Form Factor Mini-ITX Form Factor, 170 mm x 170 mm
OS Support
Windows 7 (32/64bit) / 8.1(64bit) / 10(64bit)
* Windows 7 (32/64bit) / 8.1(64bit) for 6th Generaon Intel® Core™ Processor Family only.
* Biostar reserves the right to add or remove support for any OS with or without noce.
