20 | Chapter 2: Hardware installaon

LEDs

Below LEDs are controlled by RACING GT program. Please refer to Chapter 3.3 for more detail

soware seng.

1. RGB LED Header

2. MOSFET Heatsink LED

3. on-board LEDs (x12)
