Biostar B350GT3 Версия 6.1 [56/72] 8 led灯

18 | 第二章: 硬件安装

2�8 LED灯

LED灯

下面的LED灯由RACING GT软件控制。请参考3.3章节的软件设置。

1. RGB LED 接头

2. MOSFET散热片LED灯

3. 板载LED灯(x7)
