12 | Chapter 2: Hardware installaon
Ryzen - DDR Maximum Frequency Support Table
▪
Ryzen - Pinnacle Ridge:
Maximum Frequency DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2933 -- SR -- --
DDR4: 2400 -- DR -- --
DDR4: 2933 -- SR -- SR
DDR4: 2400 -- DR -- DR
DDR4: 2133 SR SR SR SR
DDR4: 1866 SR/DR DR SR/DR DR
▪
Ryzen - Summit Ridge:
Maximum Frequency DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2667 -- SR -- --
DDR4: 2667 -- DR -- --
DDR4: 2667 -- SR -- SR
DDR4: 2400-2667 -- DR -- DR
DDR4: 2133-2400 SR SR SR SR
DDR4: 1866-2133 SR/DR DR SR/DR DR
▪
Ryzen - Raven Ridge:
Maximum Frequency DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2933 -- SR -- --
DDR4: 2667 -- DR -- --
DDR4: 2667 -- SR -- SR
DDR4: 2400 -- DR -- DR
DDR4: 2133 SR SR SR SR
DDR4: 1866 SR/DR DR SR/DR DR
Note
»
SR-Single-rankDIMM,1Rx4or1Rx8.
»
DR-Dual-rankDIMMs,2Rx4or2Rx8.
»
ForthebeerDDR4modulecompability,pleasefollowthetabletoinstallyourDDR4modules.
