APPENDIX I: Specicaons in Other Languages | 43
B450GT3
Spanish
Especicaciones
Compabilidad con el
procesador
Ranura AM4 Soporta AMD® Serie A APU, Ryzen APU / Ryzen CPU
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el procesador.
Tipo de Placa AMD® B450
Memoria
Soporta DDR4 1866/2133/2400/2666/2933/3200(OC) Doble Canal
4x DDR4 DIMM Ranura de memoria Soporta hasta 64 GB Memoria
Cada DIMM soporta un modulo non-ECC 8/16 GB DDR4
*Por favor consultar con www.biostar.com.tw para la lista de compabilidad con el memoria.
Almacenamiento de
información
Conector 6x SATA III (6Gb/s) : Soporta AHCI & RAID 0,1,10
1x M.2 (32Gb/s) : Soporta PCI-E & SATA SSD
* M.2 (32Gb/s): El ancho de banda depende de la CPU, Ryzen es 32Gb/s ; APU & CPU es 16Gb/s.
LAN
Realtek RTL 8118AS
10/ 100/ 1000 Mb/s auto negociación, capacidad dúplex Mitad/Completo
Códec Audio
ALC1150
Canales Audio de Alta Denición 7.1, Hi-Fi(Front)
USB
Ranura 1x USB 3.1 Gen2 (10Gb/s) TYPE-C (1 en las entrada/salidas posteriores)
Ranura 1x USB 3.1 Gen2 (10Gb/s) TYPE-A (1 en las entrada/salidas posteriores)
Ranura 4x USB 3.1 Gen1 (5Gb/s) - (2 en las entradas/salidas posteriores y 2 por los distribuidores internos)
Ranura 6x USB 2.0 (2 en las entradas/salidas posteriores y 4 por los distribuidores internos)
Ranuras de Exnción
Ranura 2x PCIe 2.0 x1
Ranura 1x PCIe 2.0 x16 (x4)
Ranura 1x PCIe 3.0 x16 (Cuando se usa APU, el ancho de banda es x8 velocidad)
Panel trasero de E/S
Ratón / Teclado 1x PS/2
Ranura 1x DVI-D
Ranura 1x VGA
Ranura 1x HDMI
Ranura 1x LAN
Ranura 1x USB 3.1 Gen2 (10Gb/s) TYPE-C
Ranura 1x USB 3.1 Gen2 (10Gb/s) TYPE-A
Ranura 2x USB 3.1 Gen1 (5Gb/s)
Ranura 2x USB 2.0
Socket audio 6x
Conectores en placa
Conector 6x SATA III (6Gb’s)
Distribuidor 2x USB 2.0 (cada distribuidor soporta 2 ranuras USB 2.0)
Distribuidor 1x USB 3.1 Gen1 (5Gb/s) -(cada distribuidor soporta 2 ranuras USB 3.1 Gen1)
Conector con 8 pallas x1
Conector con 24 pallas x1
Conector Venlador procesador x1
Conector Venlador Sistema x2
Distribuidor Panel Frontal x1
Distribuidor Audio Frontal x1
Distribuidor CMOS Directo x1
Conector Externo S/PDIF x1
Distribuidor Ranura Serie x1
Distribuidor 5050 LED x2
Factor de Forma Factor de Forma uATX, 244 mm x 244 mm
Soporte OS
Windows 10(64bits)
Windows 7 (64 bits) solo para Bristol Ridge / Summit Ridge / Pinnacle Ridge
Biostar reserva su derecho de añadir o rerar el soporte para cada OS con o sin nocación.
