12 | 第二章: 硬件安装
Ryzen - DDR最高频率支持表
■
Ryzen - Pinnacle Ridge:
最高频率 DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2933 --
SR -- --
DDR4: 2400 --
DR -- --
DDR4: 2933 --
SR -- SR
DDR4: 2400 --
DR -- DR
DDR4: 2133
SR SR SR SR
DDR4: 1866
SR/DR DR SR/DR DR
■
Ryzen - Summit Ridge:
最高频率 DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2667 --
SR -- --
DDR4: 2667 --
DR -- --
DDR4: 2667 --
SR -- SR
DDR4: 2400-2667 --
DR -- DR
DDR4: 2133-2400
SR SR SR SR
DDR4: 1866-2133
SR/DR DR SR/DR DR
■
Ryzen - Raven Ridge:
最高频率 DIMMA1 DIMMA2 DIMMB1 DIMMB2
DDR4: 2933 --
SR -- --
DDR4: 2667 --
DR -- --
DDR4: 2667 --
SR -- SR
DDR4: 2400 --
DR -- DR
DDR4: 2133
SR SR SR SR
DDR4: 1866
SR/DR DR SR/DR DR
»
SR - Single-rank DIMM, 1R x4 or 1R x8。
»
DR - Dual-rank DIMMs, 2R x4 or 2R x8。
»
为了更好的DDR4模块兼容性，请按照上述列表安装您的DDR4模块。
