第三章: UEFI BIOS和软件 | 31

B450GT3

• 流星：L E D灯以特定频率滑动。

• 浪花：L E D 灯以水波纹节奏呈现。

• 星空：LED灯以特定的节奏闪烁。

• 闪电：LED灯闪烁并以特定频率滑动。

• 彩虹：LED灯以炫丽多彩的节奏律动。

• 极光：LED灯显示柔和的光线并轻微闪烁。

9� 速度慢/快：允许您控制闪烁速度。

使用VIVID LED DJ，可独立控制四种LED类型区块，不同的LED类型将配置不同的闪烁模式。
