SiE30-408 Malfunction of Transmission Examples
Cases for Examination 123
3. Malfunction of Transmission Examples
3.1 [Malfunction of Transmission Examples]
Display of Malfunction of Transmission due to the
Elevator's Power Line
Applicable
Models
VRV in general
Condition A malfunction "UE" is issued at random. It continues to be generated maximum 30 seconds.
Transmitted waveforms were checked to be distorted for a period of approx. 10 seconds on site.
Cause Out-Out transmission line had been laid next to the high-voltage line of the elevator.
Measure Request to correct wiring.
Point of
Diagnosis
3.2 [Malfunction of Transmission Examples]
Malfunction of Transmission due to Wiring next to the
High-voltage Line for Indoor Unit
Applicable
Models
VRV in general
Condition A malfunction "U4" sometimes occurred on the specific system. Its cause was not located
though the transmission waveforms on the outdoor unit side were checked.
Cause Waveforms on the indoor unit side were checked. The wiring on the indoor unit side had been
laid next to the high-voltage line.
Measure Keep the wiring of indoor unit away from the high voltage line.
Point of
Diagnosis
