Field Setting on Outdoor Unit SiE30-408
64 Field Settings from Remote Controller
4. Press the RETURN button (BS3) if the refrigerant is charged to the specified capacity. The
operation stops.
[The operation stops automatically in maximum approximately 30 minutes.
If the additional refrigerant charge is not completed within 30 minutes, set the (A) additional
refrigerant charge operation again and start to operate.
If the compressor stops soon after re-operating, the refrigerant could be over charged. The
refrigerant charging is no more available.]
5. Remove the refrigerant charge hose. Then, be sure to open liquid-side stop valve fully
immediately.(Otherwise, the piping could burst due to liquid seal.)
Operating
Condition
Frequency of compressor: 210Hz
Solenoid valve: Open (Y1S, Y2S, Y3S produced before December 2003, Y1S, Y2S
produced after January 2004)
The outdoor fan: High pressure control
The indoor expansion valve (all the rooms): 1024 pls
The indoor fan: H tap
Operating
Procedures
1. Charge the refrigerant normal way first.
Charge from the service port of liquid-side stop valve in stop state of outdoor unit.
(Close fully the liquid and gas side stop valves.)
2. Turn on the power supply of indoor and outdoor units and open the gas side stop valve fully.
(Be sure to close fully the liquid-side stop valve.)
3. Setting of service mode
4. It is completed if the refrigerant is charged to the specified capacity. If the charge is not
completed within 30 minutes, make the setting again and operate
(Pressing the check button in refrigerant additional charging operation stops the operation.)
5. Remove the refrigerant charge hose and open the liquid-side stop valve fully.
* Be sure to operate as the following only if all the refrigerant cannot be charged after trying
the charge in stop state of outdoor unit.
(Otherwise this causes malfunction.)
Press and hold the MODE button for a period of five
seconds while in "Setting mode 1" to put the system into
"Setting mode 2".
8777777
Press the SET button and set the LED display to the
refrigerant re-filling operation.
8787877
Press the RETURN button.
8777779
Press the SET button and set the LED display as shown
in the right figure.
8777797
Press the RETURN button and the setting is completed.
8777787
The operation starts when the RETURN button is
pressed again.
8977777
During operation, the system
displays the pressure level of low
pressure.
0.34MPa
8878888
0.34MPa
8877888
0.25MPa
8877788
0.15MPa
8877778
When operation is completed. (The system operation
stops within 30 minutes.)
(The display of the immediately previous pressure level
blinks.)
8877799
This pattern shows that the unit
stopped at pressure level the pressure
level of [0.25MPa or less]
