All speciﬁcations valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

AC/DC Power Supplies

TOP-100 Series 100 Watt

General Specifications

Temperature coefficient 0.02 %/K

Humidity (non condensing) 0 – 95 % rel. H max.

Efficiency – Vin = 115 VAC 89 – 91 %

– Vin = 230 VAC 90 – 92 %

Switching frequency 100 kHz typ. (pulse width modulation)

Hold-up time – Vin = 115 VAC 10 ms typ.

– Vin = 230 VAC 15 ms typ.

Start-up time – Vin = 115 VAC <3.5s

– Vin = 230 VAC <2s

Isolation voltage – Input / Output 3000 VAC

– Input / Field Ground 1500 VAC

– Output / Field Ground 500 VAC

Isolation resistance (at 500 VDC) 100 Mohm min.

Earth leakage current 250 µA max.

Reliability, calculated MTBF at +25°C acc. to IEC 61709 www.tracopower.com/overview/top100

Isolation class class II double isolation

EMC emissions – Conducted input RI suppression EN 55022, class B (conductive plane to be

connected to safety earth)

– Harmonic current emissions IEC / EN 61000-3-2, class A

EMC immunity – Electrostatic discharge ESD IEC / EN 61000-4-2

– RF field immunity IEC / EN 61000-4-3

– Electrical fast transients/burst immunity IEC / EN 61000-4-4

– Surge IEC / EN 61000-4-5

– Conducted RF IEC / EN 61000-4-6

– Voltage dip IEC / EN 61000-4-11

Safety approvals and – CB certificate IEC 60950-1

certifications – SIQ certificate EN 60950-1

– UL coc UL 60950-1

– Certification documents www.tracopower.com/overview/top100

Environment – Vibration acc. IEC 60068-2-6; 3 axis, sine sweep, 10–55Hz, 1g, 1oct/min

– Shock acc. IEC 60068-2-27 3 axis, 10g half sine, 11msShock

20 G (3 directions each 3 times)

Environmental compliance – Reach www.tracopower.com/info/reach-declaration.pdf

– RoHS RoHS directive 2011/65/EU

Connection pin connector (Molex)

Weight 140 g (4.9 oz)

Installation instructions :

www.tracopower.com/overview/top100
