Motherboard Manual
2
1.3 Motherboard Specifications
Specifications
CPU Support
Socket 1150 for Intel® Core i7 / i5 / i3 / Pentium / Celeron processor
Maximum CPU TDP (Thermal Design Power): 95Watt
* Broadwell CPU is only supported by Hi-Fi Z97Z5 & Hi-Fi Z97Z5+.
* Please refer to
www.biostar.com.tw for CPU support list.
Chipset INTEL® Z97 (Hi-Fi Z97Z5, Hi-Fi Z97Z5+) INTEL® B85 (Hi-Fi B85Z5, Hi-Fi B85Z5+)
Memory
Supports Dual Channel DDR3 1066/ 1333/ 1600
Supports Dual Channel DDR3 1800(OC) / 1866(OC) / 2133(OC) / 2200(OC) / 2400(OC) /
2600(OC) / DDR3-2800(OC) for Hi-Fi Z97Z5/Hi-Fi Z97Z5+
4 x DDR3 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8 GB DDR3 module
* Please refer to
www.biostar.com.tw for Memory support list.
Storage
INTEL® Z97:
6x SATA 6Gb/s Connector
Supports RAID 0,1,10,5, SRT & AHCI
INTEL® B85:
4x SATA 6Gb/s Connector
2x SATA 3Gb/s Connector
Supports AHCI
LAN
Realtek RTL8111GR
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
Audio Codec
ALC892
7.1 Channels, High Definition Audio, Biostar Hi-Fi
(2-channel output is from front audio header)
USB
2x USB 3.1 port (2 via internal header, only for Hi-Fi B85Z5+/ Hi-Fi Z97Z5+)
4x USB 3.0 port (2 on rear I/Os and 2 via internal headers)
8x USB 2.0 port (4 on rear I/Os and 4 via internal headers)
Expansion Slots
2x PCI Slot
2x PCIe 2.0 x1 Slot
1x PCIe 2.0 x16 Slot (x1)
1x PCIe 3.0 x16 Slot (x16)
Rear I/Os
1x PS/2 Mouse/Keyboard
1x HDMI Port
1x VGA Port
1x DVI Port
1x LAN port
4x USB 2.0 Port
2x USB 3.0 Port
3x Audio Jack
