Hi-Fi Z97Z5/Hi-Fi Z97Z5+/Hi-Fi B85Z5/Hi-Fi B85Z5+
49
Specyfikacje techniczne
Wewnętrzne porty
wejścia/ wyjścia
Hi-Fi Z97Z5/Hi-Fi Z97Z5+
Złącza 6x SATA 6.0Gb/s
Złącza 2x USB 2.0
(każde złącze obsługuje dodatkowe 2
porty USB 2.0)
Złącze 1x USB 3.0
(każde złącze obsługuje dodatkowe 2
porty USB 3.0)
Złącze 1x USB 3.1, Hi-Fi Z97Z5+
(każde złącze obsługuje dodatkowe 2
porty USB 3.1)
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x 2
Złącze przedniego panelu x1
Złącze audio przedniego panelu x1
Złącze bezpośrednie CMOS x1
Złącze konsument IR x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Hi-Fi B85Z5/Hi-Fi B85Z5+
Złącza 4x SATA 6.0Gb/s
Złącza 2x SATA 3.0Gb/s
Złącza 2x USB 2.0
(każde złącze obsługuje dodatkowe 2 porty
USB 2.0)
Złącze 1x USB 3.0
(każde złącze obsługuje dodatkowe 2 porty
USB 3.0)
Złącze 1x USB 3.1, Hi-Fi B85Z5+
(każde złącze obsługuje dodatkowe 2 porty
USB 3.1)
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x 2
Złącze przedniego panelu x1
Złącze audio przedniego panelu x1
Złącze bezpośrednie CMOS x1
Złącze konsument IR x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Obudowa Obudowa ATX, 305 mm x 210 mm
Obsługa OS
Windows 7/ 8/ 8.1
Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z
wypowiedzeniem lub bez wypowiedzenia.
