Motherboard Manual
26
4.4 INTEL SMART RESPONSE TECHNOLOGY
With Intel(R) Smart Response Technology, the performance of RAID with an Intel
SSD drive can be improved better.
Installing Smart Response Technology
1. Install RAID drives (RAID 0, 1, 5) and an Intel SSD.
2. Activate RAID mode from BIOS, and install operating system.
3. Insert the Setup DVD to the optical drive, and Install all drivers (including
Intel(R)
Smart Response Technology Driver). After all processes finish,
reboot the system.
4. Intel(R) SRT service icon will show in notification area. Double click it to
open the main windows.
5. Select “Accelerate” page, and make sure the status of accelerated device
has been enabled accelerated.
