Motherboard Manual
66
JAPANESE
仕様
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pentium / Celeron プロ
セッサ (TDP: 95W)
Execute Disable Bit / Enhanced Intel SpeedStep® /
Intel Architecture-64 / Extended Memory 64
Technology / Virtualization Technology / Hyper
Threadingをサポートします
チップセット
Intel Z77 (Hi-Fi Z77S), Intel H77 (Hi-Fi H77S)
メインメモリ
DDR3 DIMMスロット x 4
最大メモリ容量32GB
各DIMMは 512MB/1GB/2GB/4GB/8GB DDR3
をサポート
デュアル チャンネルモードDDR3メモリモジュール
DDR3 1066 / 1333 / 1600 をサポート
DDR3(OC) 1800/2000/2200/2400/2600 をサポート
DDR3(OC) 1866/2133 (Hi-Fi Z77S) をサポート
登録済みDIMMとECC DIMMはサポートされません
Super I/O
IT8728F
もっとも一般に使用されるレガシーSuper I/O機
能を採用しています。
低ピンカウントインターフェイス
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
SATA 2 & 3
統合シリアルATAコントローラ
最高3.0 Gb/秒 / 6.0 Gb/秒のデータ転送速度
SATAバージョン2.0 / 3.0仕様に準拠。
RAID 0,1,5,10, SRT のサポート
LAN
Realtek RTL 8111F
10 / 100 / 1000 Mb/秒のオートネゴシエーション
半/全二重機能
HDオーディ
オのサポート
ALC892
ハイデフィニションオーディオのサポート
7.1 チャンネルオーディオアウト, Biostar Hi-Fi
USB3.0
Z77/ H77 データ転送速度最大600 MB /秒の
PCIスロット x2
PCI Express Gen3 x16スロット x1
PCI Express Gen2 x16スロット(x4) x1
スロット
PCI Express Gen2 x 1スロット x2
SATA3コネクタ x2 各コネクタは1つのSATA3デバイスをサポートします
SATA2コネクタ x4 各コネクタは1つのSATA2デバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
オンボードコ
ネクタ
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
