IMPORTANT INSTALLATION
SPECIFICATIONS
The installer should note that the appliance that side
walls should be no higher than the hot plate itself.
Furthermore, the rear wall, the surfaces surrounding
and adjacent to the appliance must be able to withstand
an overtemperature of 65K.
The adhesive used to stick the plastic laminate to the
cabinet must be able to withstand a temperature of not
less than 150° C otherwise the laminate could come
unstuck.
The appliance must be installed in compliance with the
provisions in force.
This appliance is not connected to a device able to
dispose of the combustion fumes. It must therefore be
connected in compliance with the above mentioned
installation standards. Particular care should be paid to
the following provisions governing ventilation and
aeration.
5) ROOM VENTILATION
It is essential to ensure that the room in which the
appliance is installed is permanently ventilated in order
to allow the appliance itself to operate correctly. the
necessary amount of air is that required for regular gas
combustion and ventilation of the relative room, the
volume of which must not be less than 20 m
3
. Air must
naturally flow through permanent openings in the walls
of the room in question. These openings must vent the
fumes outdoors and their section must be at least
100 cm
2
(see fig. 3). Construction of the openings must
ensure that the openings themselves may never be
blocked. Indirect ventilation by air drawn from an
adjacent room is also permitted, in strict compliance
with the provisions in force.
CAUTION: if the burners of the cooking top are
without safety thermocouple, the ventilation outlet
must have a minimum 200 cm² section.
6) LOCATION AND AERATION
Gas cooking appliances must always dispose of their
combustion fumes through hoods. These must be
connected to flues, chimneys or straight outside. If it is
not possible to install a hood, an electric fan can be
installed on a window or on a wall facing outside
(see fig. 4). This must be activated at the same time as the
appliance (see fig. 5), so long as the specifications in the
provisions in force are strictly complied with.
INSTALLATION
39
