40
7) GAS CONNECTION
Before connecting the appliance, check that the values
on the data label affixed to the underside of the hot plate
correspond to those of the gas and electricity mains in
the home.
A label on the appliance indicates the regulating
conditions: type of gas and working pressure. Gas
connection must comply with the pertinent standards
and provisions in force.
When gas is supplied through ducts, the appliance must
be connected to the gas supply system:
o with a rigid steel pipe. The joints of this pipe must consist
of threaded fittings conforming to the standards.
o With copper pipe. The joints of this pipe must consist of
unions with mechanical seals.
o With seamless flexible stainless steel pipe. The length of
this pipe must be 2 meters at most and the seals must
comply with the standards.
When the gas is supplied by a bottle, the appliance must
be fuelled by a pressure governor conforming to the
provisions in force and must be connected:
o with a copper pipe. The joints of this pipe must consist of
unions with mechanical seals.
o With seamless flexible stainless steel pipe. The length of
this pipe must be 2 meters at most and the seals must
comply with the standards. It is advisable to apply the
special adapter to the flexible pipe. This is easily available
from the shops and facilitates connection with the hose
nipple of the pressure governor on the bottle.
o With rubber hose pipe in compliance with standards. The
diameter of this hose pipe must be 8 mm and its length
must be no less than 400 mm and no more than 1500
mm. It must be firmly fixed to the hose nipple by means of
the safety clamp specified by standards.
At the connection end, verify the gasproof using a soap solution,
never a flame.
WARNINGS:
remember that the gas inlet union on the appliance
is a 1/2" gas parallel male type in compliance with
EN 10226 standards.
- The appliance complies with the provisions of the
following CEE Directives:
90/396 + 93/68 regarding gas safety.
INSTALLATION
