Biostar Hi-Fi A55S2 Версия 6.x [46/55] Japanese
![Biostar Hi-Fi A55S2 Версия 6.x [46/55] Japanese](/views2/1708403/page46/bg2e.png)
Motherboard Manual
44
Japanese
仕様
CPU サポート
AMD A-シリーズ プロセッサの Socket FM2
最大 CPU TDP （Thermal Design Power 最大放熱量）:100 W
*CPU サポート リストについては、
www.biostar.com.twを参照してください。
チップセット
AMD A85 FCH (Hi-Fi A85S2)
AMD A75 FCH (Hi-Fi A75S2)
AMD A55 FCH (Hi-Fi A55S2)
メモリ
デュアルチャンネル DDR3 800/ 1066/ 1333/ 1600/ 1866 をサポート
2 x DDR3 DIMM メモリ スロット、 最大 32 GB メモリまでサポート
各 DIMM は、 非-ECC 512MB/ 1/ 2/ 4/ 8/ 16 GB DDR3 モジュールをサポートしてい
ます
*サポートされているメモリのリストについては、
www.biostar.com.twを参照してく
ださい。
保存スペース
AMD A85/A75/A55 FCH
RAID 0,1,10, 5 & AHCI のサポート (A85 FCH)
RAID 0,1,10 & AHCI のサポート (A75/A55 FCH)
LAN
Realtek RTL 8111F
10/ 100/ 1000 Mb/s オートネゴーシエーション、半/全 二重通信
オーディオ コーデ
ック
ALC892
5.1 チャンネル, ハイ デフィニション オーディオ, Biostar Hi-Fi
USB
AMD A85/A75 FCH:
6x USB 2.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に4つ)
4x USB 3.0 ポート (後部 I/O に2つ 及び 内蔵ヘッダー経由に2つ)
AMD A55 FCH:
8x USB 2.0 ポート (後部 I/O に4つ 及び 内蔵ヘッダー経由に4つ)
拡張スロット
3x PCI スロット
2x PCIe 2.0 x1 スロット
1x PCIe 2.0 x16 スロット
後部 I/O
Hi-Fi A85S2:
1x PS/2 キーボード
1x PS/2 マウス
1x HDMI ポート
1x VGA ポート
1x DVI ポート
1x LAN ポート
2x USB 2.0 ポート
2x USB 3.0 ポート
3x オーディオ ジャック
Hi-Fi A75S2:
1x PS/2 キーボード
1x PS/2 マウス
1x HDMI ポート
1x VGA ポート
1x DVI ポート
1x LAN ポート
2x USB 2.0 ポート
2x USB 3.0 ポート
3x オーディオ ジャック
Hi-Fi A55S2:
1x PS/2 キーボード
1x PS/2 マウス
1x VGA ポート
1x DVI ポート
1x LAN ポート
4x USB 2.0 ポート
3x オーディオ ジャック
