Hi-Fi A85S2/Hi-Fi A75S2/Hi-Fi A55S2
47
Specyfikacje techniczne
Wewnętrzne porty
wejścia/ wyjścia
Hi-Fi A85S2:
Złącza 8x SATA 6.0Gb/s
Złącza 2x USB 2.0
Złącza 1x USB 3.0
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x
2
Złącze przedniego panelu x1
Złącze audio przedniego
panelu x1
Złącze bezpośrednie CMOS
x1
Złącze port drukarki x1
Złącze konsument IR x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Hi-Fi A75S2:
Złącza 6x SATA 6.0Gb/s
Złącza 2x USB 2.0
Złącza 1x USB 3.0
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x
2
Złącze przedniego panelu x1
Złącze audio przedniego
panelu x1
Złącze bezpośrednie CMOS
x1
Złącze port drukarki x1
Złącze konsument IR x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Hi-Fi A55S2:
Złącza 6x SATA3.0Gb/s
Złącza 2x USB 2.0
Złącza 4 pionowe x 1
Złącza 24 pionowe x 1
Złącze wentylatora CPU x 1
Złącze wentylatora obudowy x
2
Złącze przedniego panelu x1
Złącze audio przedniego
panelu x1
Złącze bezpośrednie CMOS
x1
Złącze port drukarki x1
Złącze konsument IR x1
Port szeregowy x1
Port zewnętrzny S/PDIF x1
Obudowa Obudowa ATX, 295 mm x 200 mm
Obsługa OS
Windows XP / Vista / 7/ 8
Biostar zastrzega sobie prawo do dodania lub wycofania obsługi dla OS, z
wypowiedzeniem lub bez wypowiedzenia.
