www.tracopower.com Page 1 of 4
AC/DC Medical Power Supply TPP 40A Series, 40 Watt
Models
The TPP 40A Series of 40 Watt AC/DC power supplies feature a reinforced dou-
ble I/O isolation system according to latest medical safety standards IEC/EN ES
60601-1 3rd edition for 2 MOPP up to 5000 m MSL. The earth leakage current
is below 75 A what makes the units suitable for BF (body floating) applications.
The excellent efficiency of up to 92% allows a high power density for the stan-
dard 2.44” x 3.0” packaging format. The full load operating temperature range
is –40°C to +70°C while it goes up to 85°C with 50% load derating. The EMC
characteristic complies to IEC 60601-1-2 ed.4 and is dedicated for applications
in industrial and domestic fields. High reliability is provided by use of industrial
quality grade components and an excellent thermal management. It makes the
products an ideal solution for medical devices and for demanding safety and
space critical applications.
Order code Output voltage Output current max. Efficiency max.
TPP 40-105A-J
5 VDC 8.0 A 90 %
TPP 40-112A-J
12 VDC 3.34 A 92 %
TPP 40-124A-J
24 VDC 1.67 A 92 %
TPP 40-148A-J
48 VDC 0.84 A 92 %
Models
prepared
C B
Scheme
ES 60601-1
• Open frame power supply pin connector
• Certification according to IEC/EN/ES
60601-1 3rd edition for 2MOPP
• Low leakage current <75 A rated for
BF applications
• Risk management process according to
ISO 14971 including risk management file
• Acceptance criteria for electronic assem-
blies according to IPC-A-610 Level 3
• EMC emission to IEC 60601-1-2 ed.4
• Protection class I & ll
• Approved for operation up to 5000 m MSL
• Ready to meet ErP directive, < 0.15 W
no load power consumption
• 5 year product warranty
Encased version with screw terminal
connection see TPP 40 Series
www.tracopower.com/overview/tpp40
Note: - Output is ajustable by ±10% with internal potentiomet
- Other output voltages are available on request
