TPP 40A Series, 40 Watt

www.tracopower.com Page 3 of 4

All speciﬁcations valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

General Specifications

Operating temperature –40°C to +85°C

with derating

Output power de-rating 2.67 %/K above +70°C at 230 VAC

2.75 %/K above +65°C at 115 VAC

Storage temperature –40°C to +85°C

Humidity (non condensing) 5 – 95 % rel. H max.

Altitude during operation 5000 m

Switching frequency - single output 5 VDC model: 70 kHz typ. (pulse frequency modulation)

(at 230 VAC) other models: 120 kHz typ. (pulse frequency modulation)

Isolation voltage – Input / Output (60 s) 4000 VAC

(2 x MOPP insulation) – Input / PE or Floating (60 s) 2500 VAC

Leakage current (at 264 VAC/60Hz) 75 µA max.

Isolation resistance (at 500 VDC) 100 MOhm min.

Reliability – calculated MTBF at +25°C acc. to IEC 61709 3‘000‘000 h

Protection class class II prepared

Electromagnetic compatibility – Conducted & Radiated input surpression EN 55011 limits to IEC 60601-1-2 4th editon

(EMC), emissions EN 55032 class B (internal filter)

– Harmonic current emissions IEC / EN 61000-3-2, class B

– Voltage flicker IEC / EN 61000-3-3, class B

Electromagnets compatibility (EMC), immunity IEC / EN 60601-1-2

– Electrostatic discharge ESD IEC / EN 61000-4-2, 8kV/6kV perf. criteria A

– RF field immunity IEC / EN 61000-4-3, 20V/m perf. criteria A

– Electrical fast transients/burst immunity IEC / EN 61000-4-4, ± 2kV perf. criteria A

– Surge IEC / EN 61000-4-5, ± 1kV/± 2kV perf. criteria A

– Conducted RF IEC / EN 61000-4-6, 20 Vrms perf. criteria A

– Magnetic field IEC / EN 61000-4-8, 10A/m perf. criteria A

Voltage dip and interruptions according to EN 60601-1-2 30%, 500ms perf. criteria A

reference: 100 VAC / 50Hz 60%, 100ms perf. criteria B

> 95%, 10ms perf. criteria A

> 95%, 5000ms perf. criteria B

Safety standards and certification IEC/EN 60601-1 3rd edition,

ANSI/AAMI ES60601-1:2005(R)2012

– Certification documents www.tracopower.com/overview/tpp40a

Environment – Vibration acc. IEC 60068-2-6 3 axis, sine sweep, 10–55Hz, 1g, 1oct/min

– Shock acc. IEC 60068-2-27 3 axis, 10g half sine, 11msShock

20 G (3 directions each 3 times)

Environmental compliance – Reach www.tracopower.com/products/reach-declaration.pdf

– RoHS RoHS directive 2011/65/EU

Connection JST pin connector
