TPP 40A Series, 40 Watt

www.tracopower.com Page 2 of 4

All speciﬁcations valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.

Input Specifications

Input voltage range – AC range (universal input) 85 – 264 VAC

– DC range 120 – 370 VDC

Input frequency 47 – 63 Hz

Input current at full load – at 115 VAC / 230 VAC 1.05 A max. / 0.55 A max.

Input protection T3.15 A/250 VAC (internal fuse in both line &

neutral)

Input inrush current – at 230 VAC 60 A max.

Zero load power consumption 0.15 W max. (acc. ErP directive)

Output Specifications

Voltage set accuracy ±1%

Regulation – Input variation 0.2% max.

– Load variation (0 - 100%) 5 VDC model: 0.7% max.

other models: 0.5% max.

Minimum load not required

Temperature coefficient 0.02%/K

Hold-up time – Vin = 115 VAC 25 ms typ.

Start-up time <1 s

Rise time 20 ms typ.

Ripple and noise 5 & 12 VDC output: 75 mVp-p typ.

w. cap. 10µF/25V 1206 X7R MLCC

(20MHz Bandwidth) 24 VDC output: 75 mVp-p typ.

w. cap. 1µF/50V 1206 X7R MLCC

48 VDC output: 150 mVp-p typ.

w. cap. 0.1µF/100V 1206 X7R MLCC

Overvoltage protection 125 – 140% of nominal Vout

Current limitation at 145% Iout typ.

Short circuit protection hiccup mode (automatic recovery)

Transiente response – Peak deviation 3% max. (25% load step change)

– Recovery time 600 µs typ.

Capacitive load 5 Vout model: 16‘000 µF max.

12 Vout model: 2‘785 µF max.

24 Vout model: 700 µF max.

48 Vout model: 175 µF max.
