User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
95
4.2.12.7 LLDP Device Statistics
Use the LLDP Device Statistics screen to general statistics for LLDP-capable devices attached to the switch, and for LLDP
protocol messages transmitted or received on all local interfaces.
Figure 4-2-34 LLDP Configuration page screenshot
The page includes the following fields:
Object Description
• Neighbor Entries List
Last Updated
The time the LLDP neighbor entry list was last updated.
• New Neighbor Entries
Count
The number of LLDP neighbors for which the remote TTL has not yet expired.
• Neighbor Entries
Deleted Count
The number of LLDP neighbors which have been removed from the LLDP remote
systems MIB for any reason.
• Neighbor Entries
Dropped Count
The number of times which the local remote database dropped an LLDPDU
because of insufficient resources.
• Neighbor Entries
Age-out Count
The number of times that a neighbor’s information has been deleted from the
LLDP remote systems MIB because the remote TTL timer has expired.
