1.4 Specification

Model FST-801 FST-802 FST-802S15 FST-802S35 FST-802S50 FST-806A20 FST-806B20

Hardware Specification

Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX

Ports 1 10/100Base-TX port , 1 100Base-FX port

Fiber connector ST SC SC SC SC SC, WDM SC, WDM

Wavelength Deploy-

ment

1310nm (Transmit and Receive) 1310 (TX)

1550 (RX)

1550 (TX)

1310 (RX)

Cable 10Base-T: 2-pair Cat. 3,4,5 UTP cable, up to 100 meters

100Base-TX: 2-pair Cat. 5 UTP cable, up to 100 meters

100Base-FX: 50/125μm or 62.5/125μm multi-mode fiber cable, up to 2km. 9/125μm single-mode cable,

provide long distance for 15/20/35/50km

Maximum Cable dis-

tance

MM, 2km MM, 2km SM, 15km SM, 35km SM, 50km SM, 20km

Single wire

SM, 20km

Single wire

LED indicator System: PWR

TP: LNK/ACT, FDX/COL, 100

FX: LNK/ACT, FDX/COL

DIP switch Fiber (HDX/FDX), UTP (Auto-negotiation / Manual), speed (10/100Mbps), duplex mode (Half / Full

duplex mode), LLR (Disable / Enable), LLCF (Disable / Enable)

Speed Ethernet: 10/20Mbps for half / full-duplex

Fast Ethernet: 100/200Mbps for half / full-duplex

Power input DC 5V 2A

Power consumption 6.2 Watts / 21 BTU (maximum)

Operate environment 0~50 Degree C, 5%~90%RH

Storage environment -20~70 Degree C, 5%~90%RH

Dimension (W x D xH) 81 x 94 x 26mm

Weight 0.22kg

Emission FCC Class B, CE mark
