TH55B HD BIOS Manual
10
Execute-Disable Bit Capability
This item allows you to configure the Execute Disabled Bit function, which protects
your system from buffer overflow attacks.
Options: Enabled (Default) / Disabled
Intel (R) HT Technology
Hyper Threading Technology can improve performance by splitting instructions into
multiple streams.
Options: Enabled (Default) / Disabled
Active Processor Cores
This item allows you to set the number of cores to enable in each processor package.
Options: All (Default) / 1 / 2
A20M
Legacy OSes and APs may need A20M enabled.
Options: Disabled (Default) / Enabled
SuperIO Conf iguratio n
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Allows BIOS to Select
Serial Port1 Base
Addresses.
Configure ITE8721 Super IO Chipset
Serial Port1 Address [3F8/IRQ4]
Parallel Port Mode [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Onboard CIR Port [Disabled]
Keyboard PowerOn [Disabled]
Mouse PowerOn [Disabled]
Restore on AC Power Loss by IO[Power Off]
