TH55B HD BIOS Manual
4
IDE/SATA Configuration
The BIOS will automatically detect the presence of IDE/SATA devices. There is a
sub-menu for each IDE/SAT A device. Select a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
IDE/SATA Configuration
SATA#1 Configuration [Compatible]
> SATA 1 Device
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
> SATA 5 Device
> Primary IDE Slave
Hard Disk Write Protect [Disabled]
IDE Detect Time Out (Sec) [35]
ATA(PI)80Pin Cable Detection [Host & Device]
SATA#2 Configuration [Enhanced]
> Primary IDE Master
Configure SATA as [IDE]
> AHCI Configuration
> SATA 6 Device
Options
IDE
AHCI
Disabled
Configure SATA as
This item allows you to choose the SATA operation mode.
Options: IDE (Default) / AHCI / Disabled
SATA#1 Configuration
This item allows you to control the onboard SATA controller.
Options: Compatible (Default) / Enhanced
SATA#2 Configuration
This item allows you to control the onboard SATA controller.
Options: Enhanced (Default) / Disabled
